Signify - Philips Lighting

Philips SmartBright Direct Panel G2

R 678.00 ZAR
R 678.00 ZAR
Sale Sold out
Tax included.
Size
Colour Temperature

The new Philips Smartbright Direct panel offers exceptional value. It is perfect for your everyday ceiling lighting installations. It is available in two standard sizes and two different CCT options to suit your needs.

Product family information

The most affordable LED panel delivering comfortable light with excellent uniformity. Slimmer than its predecessor, it is durable,energy-efficient and comes with a 3-year warranty.

Options

RC048B LED32S/840 PSU W60L60 NOC GM - 840 600x600

RC048B LED32S/865 PSU W60L60 NOC GM - 865 600x600

RC048B LED50S/840 PSU W60L120 GM - 840 1200x600

RC048B LED50S/865 PSU W60L120 GM - 865 1200x600

Benefits

  • 30K hrs, 3 year warranty
  • Flicker Free – Ripple ≤ 5%


Features

  • 30K hrs, 3 years warranty
  • Suitable for different mounting applications: Recessed, PCV, Suspension
  • CRI 80
  • SDCM ≤5
  • Surge protection: 1KV/0.5KV

Applications

  • Offices
  • Hospitality
  • Fashion

Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Specifications

General information

Light source clour - 840 neutral white

Optical cover/lens type - Polycarbonate liner

Control interface - NA

Protection class IEC - Safety class II

CE Mark - yes

Number of products on 16A type B MCB - 117

Light source engine type - LED

Operating and electrical

Input Voltage - 220 to 240 V

Input Frequency - 50 to 60 Hz

Power Factor (Min) - 0.9

Controls and dimming

Dimmable - No

Mechanical and housing

Housing material - Polycarbonate

Optical cover/lens material - Polycarbonate

Optical cover/lens finish - Opal

Overall length - 600 mm

Overall width - 70 mm

Overall height - 27 mm

Colour - White

Approval and application

Ingress protection code - IP20

Mech. impact protection code - IK03

Initial performance (IEC compliant)

luminious flux (system flux) - 1600 lm

luminous flux tolerance - +/-10%

LED luminaire efficacy - 100 lm/W

Colour temperature - 4000 K

Colour rendering index - >80

Input power - 16 W

Power consumption tolerance - +/-10%

Application conditions

Ambient temperature range - -20 to +40 deg C

Product data

Order product name - BN005C LED15/NW L600 PSU GM

EAN/UPC - Product - 8710163369785

Order code - 911401827381

Numerator - Quantity Per Pack - 1

Numerator - Packs per outer box - 50

Material Nr. (12NC) - 911401827381

Net Weight (Piece) - 0.220 kg
